Hardware Installation 5
Hardware Installation
How to Use this Document
You can use the interactive Table of Contents to locate the information you need.
Red, underscored items are links to URLs. Blue, underscored items are links
within this document or to another document on the media.
Note: If you copy this document from the ftp/web or CD and do not use the
procedure discussed on the CD, you will get an error message when selecting
hyperlinks outside of this document.
Installation Overview
The DeviceMaster RTS enables communications with serial devices over an
Ethernet network. The RTS provides for remote management, configuration, and
connectivity through its 10/100BASE–T Ethernet connection.
Use the links below to locate installation procedures for the following models:
Note: The DeviceMaster Primo is not supported in this document.
Ports Model Description Installation Procedure
1
DB9 serial port with one
Ethernet port
RTS 1-Port Installation
on Page 6
1 Embedded system
Appendix A.
RTS 1-Port Embedded
System Installation on Page 33
4
DB9 or RJ45 serial ports
with two Ethernet† ports
RTS 4/8-Port Installation
on Page 7.
8
DB9 or RJ45 serial ports
with two Ethernet† ports
RTS 4/8-Port Installation
on Page 7
16
RJ45 serial ports with two
Ethernet† ports
RTS 16-Port Installation - External
Power Supply on Page 8
16
RJ45 serial ports with one
Ethernet port
RTS 16/32RM Installation - Internal
Power Supply on Page 10
32
RJ45 serial ports with one
Ethernet port
RTS 16/32RM Installation - Internal
Power Supply on Page 10
† One of the Ethernet ports on the DeviceMaster RTS 4/8/16 models is a
built-in downstream port for daisy-chaining DeviceMaster systems or
other network-ready devices.
Default Network Settings
IP address:
192.168.250.250
Subnet mask:
255.255.0.0
Gateway address:
192.168.250.1
