This manual covers the Sentinel S35.
Before commencing installation of the Smoke Screen ensure that you have all of the following equipment supplied in
the box:
● 1 x Smoke Screen.
● 1 x Mounting bracket.
● 1 x smoke fluid consumable.
● 2 x 12v batteries.
● 1 x literature pack and warning sign.
You will also need:
● Mains power supply; an un-switched 13 amp fused spur connected to a dedicated breaker.
● Connections into the alarm panel or other triggering system.
● PIR (or equivalent) to provide the hold-off where required.
The Smoke Screen is designed to form part of an existing intruder alarm system but may also be configured as a
‘stand-alone’ system or as part of a centrally monitored, command and control system. A typical installation is shown
in the following schematic:
