12 UMC 600IS Installation Manual
Parameter Description Values
1 Graduations NTEP to 10,000 (80,000 available).
2 Display resolution 1, 2, 5, 10, 20, 50, 100
3 Decimal point 0, 0.0, 0.00, 0.000, 0.0000
4 Span select Parameter 4 is not configurable: Span selection is automatically set for the
following ranges: Lo = 1.7 – 3.3 mV/V; Hi = 0.5 – 2.0 mV/V
5 Digital averaging 1, 2, 4, 8, 16, 32, A1 = 8-4-2; A2 = 16-8-2
6Tare mode ATNR, AUTO, FIXED, BOTH (inhibit with motion)
7 AZM band Off, 0.5, 1, 3, 5, and 10 divisions
Use 0.5 for H-44, bench, counter and livestock applications; use 3 for vehicle,
axle-load, and railroad scales
8 AZM/PAZ aperture ±1.9%, 100% of capacity includes push-to-zero, H-44: 1.9%
9 Motion Off, 1, 3, 5, 10, 20, 50 divisions H-44: vehicle, axle, livestock, RR, 3.0; all other 1.0
10 Displayed units Lb and kg conversion
11 Setpoint mode Not supported
12 Zero band Not supported
13 Weigh mode Not supported
14 Serial output Port 1, demand, continuous, baud rate, G/T/N, or display (Port 2 not supported)
Table 3-1. Parameter Overview
Figure 3-4. Configuration Menu
XXXXXXX XXXXXXXXXXXXXX
GRADS
1
5
2
10
0.0
0.00
OPTION 5
OPTION 4
OPTION 3
OPTION 1 OPTION 2SERIAL
CALIBR
CONFIG
RES
resolution
DECPT
decimal point
50
20
100
OPTION 6
100
selection
list,
see table 3-2
on page 15
0.000
0.0000
1
4
2
8
AVERAGE
digital average
A1=8-4-2
16
32
ATNR
AUTO
A2=16-8-2
FIXED
BOTH
OFF
0.5
1
3
5
10
1.9
FS
TARE
enable tare
AZM
band
AZM/PAZ
band
1
Off
3
10
5
20
kg
lb
lb. conversion
MOTION
band
DISPLAY
50
SETPOINT
MODE
Not
supported
ZERO BAND
MODE
OPTION 7
WEIGHING
MODE
SERIAL
serial output
port 1
demand
continous
baud rate
G/T/N
display
Not
supported
Not
supported
