Normal Weighing Mode Operations 35
5.6.2 Demand Mode versus Continuous Data Output
Demand mode is used to interface with printers and
requires a manual Print command from the front panel
to initiate the output data. To comply with
legal-for-trade regulations, demand output data is
inhibited during the following conditions:
• Scale in motion
• Positive overload
•Negative overload
•Negative gross weight displayed
•Unit in display check mode
NOTE: In legal-for-trade applications, the Motion
Detection Parameter (Parameter 9) must be turned ON.
In demand mode, the operator may choose to print
Gross/Tare/Net when in net mode. If the serial port is
set to Print on Demand mode, the format is:
<STX><POL><DATA><SP><LB/KG><SP><GR/NT>
<SP><CR><LF>
General Continuous Mode Output Data Format
Continuous mode is used to interface to computers,
scoreboards, and other remote devices requiring
constant data updating. Continuous mode
transmission occurs at the end of each display update.
<STX><POL><DATA><L/K><G/N><STAT><CR><LF>
Downloading/Recall Commands
The format for fixed tare data entry (see Table 5-5) is:
<FE>(XXXXXX)<CR>
The format for fixed tare data recall (see Table 5-5) is:
<FR>(XXXXXX)<CR>
NOTES:
• Response data (xxxxxx) is six characters with
no decimal point, seven with decimal point.
Leading zeroes are shown as space characters.
•Invalid data requests or entries are responded
to with an echo of valid portion and the letter
I indicating the invalid portion.
Character Identification Definition
<,> Bracket delimiters are not sent
SE Setpoint entry (53H, 45H)
SR Setpoint recall (53H, 52H)
FE Fixed tare entry (46H, 45H)
FR Fixed tare recall (46H, 45H)
n Setpoint parameter 0-6
( Data opening parenthesis (28H)
) Data closing parenthesis (29H)
CR Command terminator (0DH)
xxxxxx DATA characters must be six or less including
decmal point if configured: 999999 or 999.99.
Space and polarity characters can not be used
in fixed tare data entry.
Table 5-5. Data String Characters
