36 UMC 600IS Installation Manual

6.0 Appendix

6.1 Error and Status Messages

The UMC 600IS indicator provides a number of error and status messages. When an error occurs, the message is

shown on the indicator display. Table 6-1 lists these messages and their meanings.

Error Message Description Solution

Err1

Loss of conﬁguration Reconﬁgure

Err1a

Loss of option conﬁguration

Err1b

Err1c

Err2

Loss of zero calibration Recalibrate

Err3

Loss of span calibration

Err5

Loss of auto tare Acquire tare

Err6

Loss of auto zero Acquire zero

Err9

Not in span calibration Program span value before entering

Err 10H

Input > 3.3 mV/V at full scale Recalibrate span to set full scale in the range 0.4–3.3 mV/V

Err 10L

Input < 0.4 mV/V at full scale

Err 10P

PTZ (push to zero) > 2% Perform zero calibration

Err 10–

PTZ > weight used for span calibration

Gross overload Check load cell wiring

Gross underrange

CAL

Calibration successful —

Table 6-1. UMC 600IS Error and Status Messages
