2.0 SYSTEM INSTALLATION AND OPERATION
2.1 Product Description
2.1.1 Handpiece Descriptions
The MicroChoice Small Shaver Handpiece (MC9840) and E9005 High Speed
Shaver Handpiece are designed to operate Micro Hub Shaver burs and shaver
blades for resection of bone and soft tissue. For operating speeds, please refer
to section
“4.0 TECHNICAL SPECIFICATIONS”. These handpieces are equipped
with a quick-connect, blade-locking collet that rotates 360° for cutter window
positioning. These handpieces can only be operated by a footswitch.
1. Blade Rotatable Locking Collet - Provides simple and fast insertion
and removal of the blade. Allows 360° positioning of the blade
cutting window.
2. Suction Port Valve - Manually controls suction flow.
3. Suction Port - Connects to the suction line for aspiration.
4. Integrated Handpiece Cord - Attaches the handpiece to the console.
