Figure 3.5 Setup
Revolving knob key to select different function. The Corresponding function and the adjustable
ranges are showed in table3.1.
Table 3.1 The setup function and adjustable ranges
No Function Adjustable Ranges
1 ALM SET(Alarm Setup) Enter Alarm Setup
2 PAT SET(Patient Setup) Enter Patient Setup
3 SYSTEM SET(System Setup) Enter System Setup
4 REVIEW(Waveform Review) Enter Waveform Review
5 PRINT SET(Print Setup) Enter Print Setup
6 MONI TYPE(Monitor Mode) Optional: single, twins the default is
single fetus
7 LANGUAGE(Language Selection) Optional: Chinese (CH), English (EN),
the default is EN.
8 CHANNEL I(Audio Channel I
Setup)
Adjustable:1④7 and mute,
the default is 3
9 CHANNEL II(Audio Channel II
Setup)
Adjustable:1④7 and mute,
the default is 3
10 CHANNEL(Audio Channel) Optional: I, II, fetal heart audio come
from the selected channel.
11 EXIT Exit main menu, back to main interface
（
1
（
Alarm Setup
Revolving the knob key to enter alarm setup, the diagram is showed as Figure 3.6:
