Note: Screw tightly the knob of ECG cable's plug after it is inserted to the ECG connector.
10.3 Check-List for Electrodes and ECG cables
Electrode Location Electrode Symbol Plug No.
Right Arm RA/R 9
Left Arm LA/L l0
Left Leg LL/F 11
Right Leg RL/N 14
Chest 1 Vl/Cl 12
Chest 2 V2/C2 1
Chest 3 V3/C3 2
Chest 4 V4/C4 3
Chest 5 V5/C5 4
Chest 6 V6/C6 5
