8
Telehealth medical diagnostic system IDIS2GO
Picture 2: Choice interface Picture 3: Examination
6.1.3 Main interface
Picture 4: The interface of the main parameters
a) The interface of the main parameters: displays the ratio of the predicted value and the measured value of
the three main parameters. The ratio shows the state of health, the correct parameters of personal information are
the key for obtaining an accuracy ratio. In addition, this interface can also display battery status, time, test number
and health indicator, as shown in the Picture 4.
b) Health indicator: shows the ratio of the measured value and the predicted value, this will reflect the state
of health (Pic. 4). Compares the measured value with the reference value in the same situation. When the value is
less than 50%, only the red indicator is displayed, what means that the patient must pay attention and go to the
hospital in time. When the value is in the range of 50% -80%, the red and yellow indicators are displayed, i.e. this
should be noted. When the value is above 80%, the red, yellow and green indicators are displayed, i.e. the patient is
healthy. The defined health indicator element is optional; it can be set to “Mark values” in the “Data management”
section.
c) Interface of other parameters: displays four parameters except the main parameter, as shown in the
Picture 5.
d) In the interface【Main parameters】 enter the 【Other parameters】 【Volume diagram】 【Volume
time diagram】using the “up” and “down” buttons as shown in the Pictures 5, 6, 7. There are four interfaces higher
in the【Main interface】.
Picture 5: Another interface of the parameters
Picture 6: Flow speed diagram
The predicted value is a reference in a
situation when information about the
patient is established (gender, age, height,
etc.).
