3. Hardware Installations
14
SPC-8520-LA , SPC-8521-LA
CPU Installation
(Only SPC-8520-LA)
:
The SPC-8520-LA supports a single Intel(R) Celeron M or Pentium M processor (FSB 400MHz). The
processor’s VID pins automatically program the voltage regulator on the CPU board to the required
processor voltage. The host bus speed is automatically selected. The processor connects to the CPU
board through the 478-pins socket.
The socket-478 contains a turn lock to secure the processor. Make sure the notch on the corner of the
CPU corresponds with the notch on the inside of the socket.
The CPU should always have a Heat Sink and a cooling fan attached to prevent overheating.
Refer to the user’s guide of optional heat sink fan appending for attachment of a heat sink fan.
(The user’s manual for the optional heat sink fan [HSF-PM] is available on the CD-ROM attached to this
product.)
CAUTION
Ensure that the CPU heat sink and the CPU top surface are in total contact to avoid CPU overheating
problem that would cause your system to hang or be unstable.
