3. Hardware Installations
SPC-8520-LA, SPC-8521-LA
13
3. Hardware Installations
This chapter provides information on how to use the jumpers and connectors on this product in order to
set up a workable system.
Installation procedure
(1) Confirm the power supply is off.
(2) Install the processor with correct orientation. (only SPC-8520-LA)
(3) Install the fan on top of the processor and connect it to the CNJI connector.
(Only SPC-8520-LA)
(4) Insert the DRAM module with correct orientation.
(5) The jumpers are set up according to the conditions to be used.
(6) Insert all external cables (Hard disk, floppy, keyboard, Mouse, LAN, etc.)
(7) Insert the monitor to the analog RGB connector (CNV1).
(8) Turn on the power.
(9) Enter the BIOS setup mode by pressing ‘Del’ key during boot up.
(10) Use the “Load BIOS Optimized Defaults” feature.
(11) Configure the Peripheral Setup and the Standard Setup correctly.
CAUTION
The CMOS memory may be in an undefined state at power-on after a period of no battery backup.
