4. Jumper Setting
SPC-8520-LA, SPC-8521-LA
29
4. Jumper Setting
RS-422A/485 Terminator: JP1
Table 4.1. RS-422A/485 Terminator
JP1 Terminator
---
CTS for RS-422A
RTS for RS-422A
RXD for RS-422A/485
TXD for RS-422A/485
Function
Terminating resisiter provided
Terminating resisiter provided
Terminating resisiter provided
Terminating resisiter provided
No terminating resister
(Default)
102
91
102
91
102
91
102
91
102
91
