2. System Reference
SPC-8520-LA, SPC-8521-LA
7
2. System Reference
Specifications
Table 2.1. Functional Specifications <1/2>
Type
SPC-8520-LA SPC-8521-LA
CPU
Option:
Intel(R) Pentium(R) M Processor
1.6G - 2.0GHz (FSB400MHz),
Intel(R) Celeron(R) M Processor
1.3G - 1.5GHz (FSB400MHz)
478pin FC-PGA
Intel(R) Celeron(R) M Processor 800MHz
(FSB400MHz)
(Fan less mounting)
Cache Built in CPU None
Processor socket Socket 478 None
Memory(Option) Max.1GB, 200 pin SO-DIMM socket x 1, PC2100 (DDR266) DDR SDRAM
Chipset Intel(R) 852GM + ICH4
BIOS Award BIOS, PnP support
VGA
Built in Intel 852GM
One Analog RGB I/F (One HD-SUB 15pin connector),
One LVDS(18bit) I/F (One box-header 30-pin connector)
Keyboard / Mouse connector
One PS/2 keyboard/Mouse connector(Bundled the 2 in 1 cable) ,
One box-header 5-pins connector for external keyboard
Serial I/F
16550 UART
Two box-header 10-pin connector (RS-232C x 1, RS-232C/422A/485 x 1),
Baud rate: 50 - 115,200bps (programmable)
Parallel I/F
One box-header 26-pin connector,
One high-speed parallel port, support SPP/EPP/ECP mode
On board expansion bus None
LAN Port
100BASE-TX/10BASE-T, Intel ICH4 integrated controller
One RJ-45 connector, Wake On LAN support
IDE I/F
One IDE port, up to two IDE devices,
One box-header 40-pin connector, support Ultra DMA 33/66/100
SATA I/F None
FDD I/F
One FDD port, up to two floppy drives (720KB, 1,44MB, 2.88MB),
One box-header 34-pin connector, 3.5inch 2mode I/F.
CF Slot *1 Type I x 1, IDE secondary port connection, Support booting
SSD Socket None
USB Port 2ch USB2.0 compliant ports, Two USB Type A connectors (on bracket)
RAID None
Audio AC97 CODEC, One pin-header 10-pin connector for line-out, line-in, microphone-in.
Watchdog Timer
1 - 255sec, 255 level
When time up: RESET
General-purpose I/F None
Hardware Monitor
Monitoring of the temperature of CPU and board, power supply voltage, and fan speed
(Function of the Winbond W83627HG)
