3. Hardware Installations
SPC-8520-LA, SPC-8521-LA
15
Audio Connector: CNA1
This connector connects the Audio jack cable.
Table 3.1. Audio Connector
Pin No.
2
4
6
8
10
Function
LINE-OUT-L
GND
MIC-IN
GND
LINE-IN-L
Pin No.
1
3
5
7
9
Function
LINE-OUT-R
GND
N.C.
GND
LINE-IN-R
CNA1
21
109
Main Memory Installation: CND1
This product support one single-side or double-sided DDR200(PC1600)/266(PC2100) unregistered
SO-DIMM, 200-pin SO-DIMM sockets for a maximum memory of 1GB. Using the non-ECC DDR
SDRAM SO-DIMM.
The CPU board supports the following memory features:
- 200-pin SO-DIMM with gold-plated contacts
- 200 MHz (PC1600)/266 MHz (PC2100) DDR SDRAM
- Non-ECC DIMM
- Unbuffered, unregistered single-sided or double-sided SO-DIMMs
Table 3.2. DDR SDRAM
SO-DIMM Size Non-ECC
128MB 16Mbit x 64
256MB 32Mbit x 64
512MB 64Mbit x 64
1024MB 128Mbit x 64
CAUTION
All memory components and DIMM used with this product must comply with the PC SDRAM
Specification. These include : the PC SDRAM Specification (memory component specific), the PC
Unbuffered DIMM Specification, and the PC Serial Presence Detect Specification.
