System Overview 2-1
2. System Overview
The Full Scale Scanner uses single, dual, triple, or quadruple 8000
pixel CCD Cameras with individual adaptive light compensation on
each pixel. The FSS includes the following features:
• FSS18300
DSP
: Up to 1800 dpi scan resolution at all original sizes;
64.800 dots at 1800 dpi, scanned at the max. scan width 36" (914
mm), by graytone interpolation and re-sampling of the physical
32.000 pixels (four cameras).
• FSS12300
DSP
: Up to 1200 dpi scan resolution at all original sizes;
43.200 dots at 1200 dpi, scanned at the max. scan width 36" (914
mm), by graytone interpolation and re-sampling of the physical
24.000 pixels (three cameras).
• FSS8300
DSP
: Up to 800 dpi scan resolution at all original sizes;
28.800 dots at 800 dpi, scanned at the max. scan width 36" (914
mm), by graytone interpolation and re-sampling of the physical
16.000 pixels (two cameras).
• FSS8300PLUS
DSP
: Up to 800 dpi resolution, setable in 1 dpi
increments, at all original sizes; 28.800 dots at 800 dpi, scanned
at the max. scan width 36" (914 mm), by graytone interpolation
and re-sampling of the physical 16.000 pixels (two cameras).
• FSS4300
DSP
: Up to 400 dpi resolution at all original sizes; 14.400
dots at 400 dpi, scanned at the max. scan width 36" (914 mm), by
graytone interpolation and re-sampling of the physical 8.000
pixels (one camera).
• Connection to the computer via standard SCSI Interface
• Scanning area sized from A5 up to A0 and E-Size (from 152 mm
up to 914 mm wide). Media size: 152 to 1016 mm.
• Image processing and enhancement options include: 2D-
Adaptive thresholding, histogram analysis, and on-line threshold
variation.
• On-line de-skewing and de-speckling, during simultaneous
scanning of the drawing, producing perfectly horizontally aligned
and speckle-free scans.
