Operator Panel and Indicators 3-1
3. Operator Panel and Indicators
The Full Scale Scanner’s Operator Panel layout shown overleaf is
divided into two keys and four indicators. The two operating keys are
positioned at the top: The Paper Reverse key (C), and the Paper
Feed/Forward key (A) with a Ready Indicator (B) attached. Three
indicators at the bottom: Power on (D), Wait (E), and Diagnostic (F).
The detailed function of the keys and indicators are as follows:
A, B : Paper Feed/Forward Key and Ready indicator.
Insert the drawing face down into the scanner’s insertion slot. The
green Ready Indicator (B) turns on (lights) when the drawing is
correctly positioned. Now press the Feed Forward key (A), and the
drawing will move into the start-of-scan position. The Ready
Indicator stays on (lighted), signifying that the scanner is ready to
be controlled from the computer.
During scanning the Ready Indicator blinks.
At end of scanning the Ready Indicator is again tuned on (lighted
without blinking) signifying that scanning can be repeated from the
computer, or else terminated by the operator if the Paper
Feed/Forward key is pressed to eject the drawing from the
scanner.
Pressing the Paper Feed/Forward key during scanning, stops the
current scanning process and feeds the original as long as the key
is held down.
NOTE : If the drawing is removed from the scanner manually
without pressing the Paper Feed/Forward key to eject, the Ready
Indicator will stay on. This condition can be reset by pressing the
Paper Feed/Forward key.
C : Paper Reverse Key.
The reverse key stops the current scanning process and reverses
the original as long as the key is held down.
D : Power On Indicator
Lights up when the scanner power is on.
