4-2 Operating Modes
The following table shows the number of pixels per scan line resulting
from various combinations of resolution and scan-width on the side-
aligned (lower) ruler:
Resolution: 600 dpi 400 dpi 300 dpi 200 dpi
Scan-
width:
8.5 21,600 14,400 10,800 7,200
8.0 20,352 13,568 10,176 6,784
6.0 15,240 10,160 7,620 5,088
4.0 10,176 6,784 5,088 3,392
3.0 7,620 5,080 3,810 2,544
2.0 5,088 3,392 2,544 1,696
The following table shows some common drawing widths and their
required scan-width settings:
Scan- Original Drawing Width*:
width:
Minimum media size of the FSS 6.0"/152mm
1.4 Minimum Scan-Width (A5) 6.0"/152mm
2.0 A-Size (letter) and approx. A4 8.5"/216mm
2.6 B-Size (11") 11.0"/280mm
2.8 A3 (297mm) 11.9"/302mm
3.0 Approx. A3 and approx. B-Size 12.7"/323mm
3.9 A2 (420mm) 16.5"/420mm
4.0 C-Size and approx. A2 17.0"/430mm
5.2 D-Size (22") 22.0"/560mm
5.5 A1 (594mm) 23.3"/592mm
6.0 Approx. A1 and approx D-Size 25.4"/646mm
7.8 A0 (841 mm) 33.1"/840mm
8.0 E-Size and approx. A0 34.0"/862mm
8.5 Maximum Scan-Width of the FSS 36.0"/914mm
Maximum Media size of the FSS 40.0"/1016mm
*The required setting for an original drawing can be measured when
the originals are inserted into the FSS using the ruler printed on top of
the original insertion slot on the Full Scale Scanner.
