6-4 Maintenance
FSS12300 Models:
1. For adjusting the left CCD Camera (when facing the front of the
scanner), follow the procedure given above for the FSS8300
models, but select a "detail window" centered about one-third in
from the left in the "overview window".
Clockwise: Line at Left side of Screen moves Down.
Counterclockwise: Line at Left side of Screen moves Up.
2. For adjusting the right CCD Camera, follow the procedure given
above for the FSS8300 models, but select a "detail window"
centered about two-third in from the left in the "overview window".
Clockwise: Line at Right side of Screen moves Down.
Counterclockwise: Line at Right side of Screen moves Up.
FSS18300 Models:
1. For adjusting the left CCD Camera (when facing the front of the
scanner), follow the procedure given above for the FSS8300
models, but select a "detail window" centered about one-quarter in
from the left in the "overview window".
Clockwise: Line at Left side of Screen moves Down.
Counterclockwise: Line at Left side of Screen moves Up.
2. For adjusting the third CCD Camera (second adjustment knob)
follow the procedure given above for the FSS8300 models, but
select a "detail window" centered about halfway in from the left in
the "overview window".
Clockwise: Line at Right side of Screen moves Down.
Counterclockwise: Line at Right side of Screen moves Up.
3. For adjusting the right CCD Camera, follow the procedure given
above for the FSS8300 models, but select a "detail window"
centered about three-quarter in from the left in the "overview
window".
Clockwise: Line at Right side of Screen moves Down.
Counterclockwise: Line at Right side of Screen moves Up.
Remember: To omit angle errors, only judge the camera height on the
repeated ”down-scans” on the screen .
