User's Manual CS1171 Hand-Held Programmer
Page 37 of 56 Control Solutions LLC
Parameter
Description
Indoor hi
When set to On, indoor input will be asserted on a high input
instead of a low input.
Unidir thrt
When set to On, the full throttle displacement controls speed only,
i.e. 0V to 5V (default forward), and direction is controlled by the
FWD/RVS input. When set to Off, throttle displacement overrides
the FWD/RVS input and controls speed and direction, i.e. 2.5V to
0V (default reverse) and 2.5V to 5V (default forward).
0V tht neut
When set to On, throttle neutral voltage will be 0V (typical 2-wire
throttle, foot pedal control). When set to Off, throttle neutral
voltage will be 2.5V (typical 3-wire throttle, wig-wag control).
AnIn throt
When set to On, the controller will respond to an analog max-
speed control directly connected to the AnIn input. AnIn must be
enabled.
MaxSpd thrt
When set to On, the controller will respond to a max-speed control
on a Deluxe display.
Invert thrt
When set to On, throttle actuation is inverted such that a default
forward actuation of the throttle results in reverse movement.
