1 Advanced parameters: General information
In some cases, the function or range of a parameter are affected by the setting of another parameter; the information in these lists
relate to the default condition of such parameters.
Key
Parameter Information example:
RW
Read-write parameter
Read-write (RW) parameter whose default
value is defined by the motor via the SLM
RO
Read-only parameter
Read-only parameter whose value is defined by
themotorviatheSLM
{...} Related Menu 0 parameter
[...] Value of a parameter
ô
range of values
ð
default values
~ indicates range of values
Uni
Unipolar variable parameter
Positive values only
Bi
Bipolar variable parameter
Positive and negative values
Txt
Text variable parameter
Alphanumeric code is displayed
Bit
Bit parameter
Two digital states only
R
Parameters must be copied to the EEPROM (saved) or
copied to the flash memory (stored) for a new value to take
effect
S
A new value is normally copied to the EEPROM (saved) or
copied to the flash memory (stored) at power-down (see
parameter 0.50 Parameter transfer function selector in
Chapter 8 Menu 0 Parameters)
P
Protected
The parameter cannot be controlled by an external signal
(cannot be a destination parameter)
n
MAX
Maximum speed of the motor
(defined by the motor via the SLM)
[SLM] Value defined by the motor via the SLM
NOTE
1.17 Keypad reference
ô ±Pr1.06 ð 0rpmROBiSP0.34
Range Default value Units Read only /
Read write
Unipolar /
Bipolar /
Bit / Txt
R / S / P Equivalent Menu
0 parameter
(where
appropriate)
Parameter
number
Parameter
description / title
