Control Techniques M'Ax User Manual

*
63 M’Ax Advanced User Guide
www.controltechniques.com Issue Number: 4
12 Menu 11 Parameters - Scale factor, Initial displayed
parameter, Serial communications, Drive information
Notes
Parameter 11.25 settings
Parameter 11.62 settings
Parameter 11.68 settings
Parameter
Range(
ô )Default( ð )
Type
11.20 Parameter 0.46 assignment selector 00.00 ~ 19.71 3.02 RW Uni
11.21 Parameter 0.46 scaling 0.000 ~ 9.999 0.1 RW Uni
11.22 Initially displayed parameter selector
00.00 ~ 13.99
menu.parameter
0.05 RW Uni
11.23 {0.37} Serial comms. address 0.0 ~ 24.7 group.unit 1.1 RW Uni
11.24 Serial comms. protocol selector 0~1 0 RW Txt P
11.25 {0.36} Serial comms. baud rate 0 ~ 6 5 (9600) RW Uni P
11.26 Serial comms. transmit-delay time 0 ~ 255 µs 2 RW Uni P
11.29 {0.48} Drive software version 01.00 ~ 99.99
RO Uni P
11.30 {0.35} User security code 0 ~ 255 149 RW Uni S P
11.32 {0.20} Drive rated current (FLC) 00.00 ~ 99.99 A
RO Uni P
11.33 Drive voltage rating 200 ~ 480 V
RO Uni P
11.34 {0.47} Drive software build number 00 ~ 99
RO Uni P
11.39 SLM software version 00.99 ~ 99.99
RO Uni P
11.51 Hardware revision 0 ~ 15
RO Uni
11.52 SLM update enable 0~1
RW Bit
11.53 SLM address 1 ~ 128
RW Uni
11.54 SLM data/command 0 ~65535
RW Uni
11.55 SLM instruction 0 ~65535
RW Uni
11.56 {0.45} SLM communications integrity 0 ~ 100%
RO Uni P
11.57 Number of errors on last instruction 0 ~ 255
RO Uni P
11.58 SLM update error indicator 0~1
RO Bit P
11.59 SLM busy indicator 0~1
RO Bit P
11.60 SLM background-read enable 0~1
RW Bit P
11.61 SLM test results 0 ~ 1
RO Bit P
11.62 SLM power-up delay 0 ~ 5 1 (250) RW Uni P
11.63 SLM buffer update 0 ~ 1 0 RW Bit
11.64 {0.17} SLM on-line enable 0~1 0 RW Bit
11.65 SLM encoder mode select 0~1 0 RW Bit
11.66 Host mode enable 0~1 1 RW Bit P
11.67 Flash update enable 0~1 0 RW Bit P
11.68 Flash device type FL28 (0) ~ FL29 (1)
RO Txt P
11.25 0123456
Baud rate
(bits/s)
300 600 1200 2400 4800 9600 19200
11.62 012345
SLM power
up delay
(ms)
0 250 500 750 1000 1250
11.68 Description
FL-28 Intel device fitted
FL-29 AMD compatible device fitted
