Control Techniques M'Ax User Manual

*
49 M’Ax Advanced User Guide
www.controltechniques.com Issue Number: 4
10 Menu 8 Parameters - Digital Input / Output Settings and
Indications
Parameter
Range(
ô )Default( ð )
Type
8.01 Digital input 1 state indicator - Digital I/O Terminal 10 0 ~ 1
RO Bit P
8.02 Digital input 2 state indicator - Digital I/O Terminal 9 0 ~ 1
RO Bit P
8.03 Digital input 3 state indicator - Digital I/O Terminal 8 0 ~ 1
RO Bit P
8.04 Digital input 4 state indicator - Digital I/O Terminal 7 0 ~ 1
RO Bit P
8.05 Digital input 5 state indicator - Digital I/O Terminal 1 0 ~ 1
RO Bit P
8.06 Digital input 6 state indicator - Digital I/O Terminal 6 0 ~ 1
RO Bit P
8.07 Digital input 7 state indicator - Digital I/O Terminal 13 0 ~ 1
RO Bit P
8.08 Digital input 8 state indicator - Digital I/O Terminal 8 0 ~ 1
RO Bit P
8.09 {0.01}
Hardware enable indicator - MCIEIA 485 / Standalone
Terminal 3
0~1
RO Bit P
8.11 Digital input 1 invert 0 ~ 1 0 RW Bit
8.12 Digital input 2 invert 0 ~ 1 0 RW Bit
8.13 Digital input 3 invert 0 ~ 1 0 RW Uni
8.14 Digital input 4 invert 0 ~ 1 0 RW Bit
8.15 Digital input 5 invert 0 ~ 1 0 RW Bit
8.16 Digital input 6 invert 0 ~ 1 0 RW Uni
8.17 Digital input 7 invert 0 ~ 1 0 RW Bit
8.18 Digital input 8 invert 0 ~ 1 0 RW Bit
8.20 Digital input / output read word 0 ~ 16384
RO Uni P
8.21
Digital input 1 destination selector
(RUN)
00.00 ~ 20.50
menu.parameter
6.34 RW Uni P
8.22
Digital input 2 destination selector
(REVERSE SELECT)
00.00 ~ 20.50
menu.parameter
6.33 RW Uni P
8.23
Digital input 3 destination selector
(JOG FORWARD)
00.00 ~ 20.50
menu.parameter
6.31 RW Uni P
8.24
Digital input 4 destination selector
(FORWARD LIMIT)
00.00 ~ 20.50
menu.parameter
6.35 RW Uni P
8.25
Digital input 5 destination selector
(REVERSE LIMIT)
00.00 ~ 20.50
menu.parameter
6.36 RW Uni P
8.26
Digital input 6 destination selector
(RESET)
00.00 ~ 20.50
menu.parameter
10.33 RW Uni P
8.27
Digital input 7 destination selector
(Preset reference select bit-0)
00.00 ~ 20.50
menu.parameter
1.45 RW Uni P
8.28
Digital input 8 destination selector
(Preset reference select bit-1)
00.00 ~ 20.50
menu.parameter
1.46 RW Uni P
8.51 Digital output 1 state indicator - Digital I/O Terminal 5 0 ~ 1
RO Bit P
8.52 Digital output 2 state indicator - Digital I/O Terminal 4 0 ~ 1
RO Bit P
8.53 Digital output 3 state indicator - Digital I/O Terminal 3 0 ~ 1
RO Bit P
8.54 Digital output 4 state indicator - Digital I/O Terminal 2 0 ~ 1
RO Bit P
8.55 Status-relay state indicator 0~1
RO Bit P
8.59 Status line indicator 0~1
RO Bit
8.60 Status line output enable 0 ~ 1
RO Bit
8.61 Digital output 1 invert 0 ~ 1 0 RW Bit
8.62 Digital output 2 invert 0 ~ 1 0 RW Bit
8.63 Digital output 3 invert 0 ~ 1 0 RW Bit
8.64 Digital output 4 invert 0 ~ 1 0 RW Bit
8.65 Status-relay invert 0 ~ 1 0 RW Bit
8.71
Digital output 1 source selector
(DRIVE RUNNING)
00.00 ~ 20.50
menu.parameter
10.02 RW Uni P
8.72
Digital output 2 source selector
(AT ZERO SPEED)
00.00 ~ 20.50
menu.parameter
10.03 RW Uni P
8.73
Digital output 3 source selector
(ALARM)
00.00 ~ 20.50
menu.parameter
10.19 RW Uni P
8.74
Digital output 4 source selector
(AT SPEED)
00.00 ~ 20.50
menu.parameter
10.06 RW Uni P
8.75
Status-relay source selector
(DRIVE HEALTHY)
00.00 ~ 20.50
menu.parameter
10.01 RW Uni P
