Analog-output scaling
When parameter 3.64 is selected, and parameter 7.20 is set at 1, 10V at Analog output 1 represents 7500rpm.
When parameter 4.04 is selected, and parameter 7.23 is set at 1, 10V at Analog output 2 represents 200% FLC.
Analog-input destination in torque mode
When the drive is in torque mode (parameter 4.11 set to 1 or 2) and controlled by an analog input, parameter 7.10 Analog input destination
selector must be set to 4.08, parameter 1.14 Reference selector mustbesetto3to5.
Summary for torque mode with analog reference
1. Set 1.14 to 3
2. Set 4.11 to 1 or 2
3. Set 7.10 to 4.08
4. Set XX.00 to 1000
5. Execute command in Edit mode
6. Power-down
7. Power-up
