3 M’Ax Advanced User Guide
www.controltechniques.com Issue Number: 4
Default settings
Use parameter 0.50 to initiate the transfer of parameter values between the RAM, EEPROM (when an option module is fitted), and the flash
memory in the drive (see Appendix H Storage and Transfer of Parameter Values in the M’Ax User Guide). After changing the setting of
parameter 0.50, perform either of the following, as appropriate:
• While the display is in Edit mode, press at the same time:
•Set10.38 at 100 via serial communications.
Terminology
Notes
At the time of selecting no, boot1 or boot2, all parameter values (including the S-parameters) are copied to the flash memory (store).
All parameters can be stored at any time by setting 11.67 Flash update enable at 1. The drive must not be powered-down within 15 seconds.
When S-parameters are not copied, the related values at the destination remain unchanged.
Main parameters can be saved irrespective of the setting of parameter 0.50 (i.e. by setting parameter XX.00 at 1000 and executing the
operation).
0.50 Parameter transfer selector
ô
See below
ð
RW Txt
Version Setting
AN no
SL boot2
Save Copy main-parameter values in the RAM to the EEPROM (when an option module is fitted)
Retrieve Copy all parameter values from the EEPROM to the RAM (when an option module is fitted)
Store Copy parameter values from the RAM to the flash memory in the drive
Restore Copy parameter values from the flash memory to the RAM
Main parameters All parameters other than those that are normally saved or stored at power-down
S-parameters Parameters that are normally saved at power-down (version _AN only)
Setting Function Usage
no 0
At power-down: S-parameter values
are copied from the RAM to the
EEPROM (save).
At power up: All parameter values are
copied from the EEPROM to the RAM
(retrieve).
Used only when an option
module is fitted (normally, in
version _AN)
rEAd 1
The main-parameter values in the flash
memory are immediately copied to the
RAM (restore).
Normally used in version _SL,
but can also be used in version
_AN
Prog 2
The main-parameter values in the RAM
are immediately copied to the flash
memory (store).
boot1 3
At power-up: The main-parameter
values in the flash memory are copied
to the RAM (restore). The values of
the S-parameters are ignored.
boot2 4
At power-up: All parameter values
(including the S-parameters) in the
flash memory are copied to the RAM
(restore).
and
