Unidrive User Guide 29
Issue Number: 9 www.controltechniques.com
3.11 RFI filters
RFI filters are available for all sizes of Unidrive as follows:
Table 3-3 RFI filters
The RFI filters can be surface-mounted only.
Mount the RFI filter following the guidelines in Figure 4-12 EMC
compliance on page 48.
Drive Filter type Schaffner part no. CT part no. Max cable size Weight
UNI1201 to 1205 Bookcase FS5111-10-29 4200-6105
4 mm
2
10 AWG
1.4kg (3lb)
UNI1201 to 1205
Footprint or
Bookcase
FS5101-10-07 4200-6104
4 mm
2
10 AWG
2.1kg (5lb)
UNI2201 to 2202 Bookcase FS5112-16-07 4200-6109
4 mm
2
10 AWG
2.7kg (6lb)
UNI2201 to 2202
Footprint or
Bookcase
FS5106-16-07 4200-6108
4 mm
2
10 AWG
2.1kg (5lb)
UNI2203 Bookcase FS5113-25-29 4200-6114
4 mm
2
10 AWG
2.7kg (6lb)
UNI2203
Footprint or
Bookcase
FS5106-25-07 4200-6113
4 mm
2
10 AWG
2.1kg (5lb)
UNI3201 to 3202 Bookcase FS5113-50-53 4200-6116
10 mm
2
6 AWG
3.8kg (9lb)
UNI3203 Bookcase FS5113-63-34 4200-6117
10 mm
2
6 AWG
3.8kg (9lb)
UNI3204 Bookcase FS5113-100-35 4200-6106
50 mm
2
1/0 AWG
7.8kg (17lb)
UNI1401 to 1405 Bookcase FS5111-10-29 4200-6105
4 mm
2
10 AWG
1.4kg (3lb)
UNI1401 - 1405
Footprint or
Bookcase
FS5101-10-07 4200-6104
4 mm
2
10 AWG
2.1kg (5lb)
UNI2401 Bookcase FS5112-16-07 4200-6109
4 mm
2
10 AWG
2.7kg (6lb)
UNI2401
Footprint or
Bookcase
FS5106-16-07 4200-6108
4 mm
2
10 AWG
2.1kg (5lb)
UNI2402 to 2403 Bookcase FS5113-25-29 4200-6114
4 mm
2
10 AWG
2.7kg (6lb)
UNI2402 to 2403
Footprint or
Bookcase
FS5106-25-07 4200-6113
4 mm
2
10 AWG
2.1kg (5lb)
UNI3401 to 3403 Bookcase FS5113-50-53 4200-6116
10 mm
2
6 AWG
3.8kg (9lb)
UNI3404 Bookcase FS5113-63-34 4200-6117
10 mm
2
6 AWG
3.8kg (9lb)
UNI3405 Bookcase FS5113-100-35 4200-6106
50 mm
2
1/0 AWG
7.8kg (17lb)
UNI4401 to 4402 Bookcase FS5113-150-40 4200-6107
95 mm
2
4/0 AWG
7.8kg (17lb)
UNI4403 to 4404 Bookcase FS5113-180-40 4200-6111
95 mm
2
4/0 AWG
15kg (33lb)
UNI4405 Bookcase FS5113-220-37 4200-6112
150 mm
2
6/0 AWG
15kg (33lb)
UNI5401 Bookcase FS113-300-99 4200-6115 M12 stud 16kg (35lb)
