Unidrive User Guide 65
Issue Number: 9 www.controltechniques.com
* Pr 0.41 PWM switching frequency has a default setting of 9kHz in
Unidrive LFT
Key:
Types of current range
FLC Full load current of the drive (maximum continuous output
current up to 40
o
C ambient temperature). Displayed in Pr 11.32
{0.33}.
I
MAX
A Maximum overload output current of the drive up to 40
o
C
ambient temperature, derived as follows:
Size 1 to 4: OL> 150% x FLC
CL> 175% x FLC
Size 5: 150% x FLC
I
MAX
% See section 8.2 Current limits on page 98 for the definition of
I
MAX
%.
Where a parameter is represented by a text value, the value in brackets
in the range column is the setting used for serial communications.
Operation mode abbreviations:
OL> Open loop
CL> Closed loop (which incorporates closed loop vector and
servo mode)
VT> Closed loop vector mode
SV> Servo
0.39 Synchronise to a spinning motor {6.09}0 or 1 01RWBit
0.40 Autotune
{
5.12}
(3.25)
0 or 1 0 RW Bit P
0.41 PWM switching frequency {5.18}
3 kHz (0), 4.5 kHz (1), 6 kHz (2), 9 kHz (3),
12 kHz (4)
3 (0)* RW Txt
0.42 Motor - no. of poles {5.11} 2 POLE (0) to 32 POLE (15) 4 POLE (1) 6 POLE (3) RW Txt P
0.43 Motor - rated power factor {5.10} 0.000 to 1.000
VT> 0.000 to 1.000
SV> 1
0.92 1 RW Uni S P
0.44 Motor - rated voltage {5.09}
200V drive: 0 to 240 V
400V drive: 0 to 480 V
200V drive: 220
400V drive: EUR> 400
USA> 460
0RWUni
0.45 Motor - rated speed {5.08} 0 to 6,000 rpm 0 to 30,000 rpm 0
EUR> 1450
USA> 1770
RW Uni
0.46 Motor - rated current {5.07} 0 to FLC A FLC RW Uni
0.47 Motor - rated frequency {5.06} 0 to 1,000.0 Hz
VT> 0 to 1,000.0 Hz
SV> 0
EUR> 50
USA> 60
0RWUni
0.48 Drive operating mode selector {11.31}
OPENLP (0), CL.VECT (1),
SErVO (2), rEGEN (3)
OPENLP
(0)
CL.VECT
(1)
SErVO
(2)
RW Txt R P
0.49 Security status 0 to 1,000 1 RO Uni P
0.50 Software version number {11.29} 1.00 to 99.99 RO Uni P
Parameter
Range(
Ú)Default(Ö)
Type
OL CL OL VT SV
RO Read Only parameter
Uni Unipolar variable parameter R Reset required for new value to take effect
Bi Bipolar variable parameter S New parameter-value saved at power-down
RW Read / Write parameter
Txt Text variable parameter P Protected; forbidden as destination parameter
Bit Bit parameter FLC Full-load current (max. continuous)
NOTE
