10.12 Menu 12: Programmable thresholds
Figure 10-15 Menu 12 logic diagram
??.??
A
ny variable
parameter
??.??
12.03
Threshold
Detector 1
input source
12.04
Threshold
Detector 1
threshold level
Threshold
Detector 1
Threshold
Detector 1
x(-1)
12.06
Threshold
Detector 1
output invert
12.01
Threshold
Detector 1
output indicator
12.05
Threshold
Detector 1
hysteresis
??.??
Any
unprotected
variable
parameter
??.??
12.07
Threshold
Detector
output
destination
parameter
1
??.??
A
ny variable
parameter
??.??
12.13
Threshold
Detector 2
input source
12.14
Threshold
Detector 2
threshold level
Threshold
Detector 2
Threshold
Detector 2
x(-1)
12.16
Threshold
Detector 2
output invert
12.02
Threshold
Detector 2
output indicator
12.15
Threshold
Detector 2
hysteresis
??.??
Any
unprotected
variable
parameter
??.??
12.17
Threshold
Detector
output
destination
parameter
2
All parameters are shown
at their default setting
All parameters are shown
at their default setting
Hysteresis
Threshold
level
Threshold
output
t
t
0.XX
0.XX
Key
Read-write (RW)
parameter
Read-only (RO)
parameter
Input
terminals
Output
terminals
The parameters are all shown at their default settings
