FLC Full load current of the drive (maximum continuous output
current up to 40
o
C ambient temperature). Displayed in Pr 11.32
{0.33}.
I
MAX
A For definition of I
MAX
, see section Types of current range on
page 138.
P
MAX
Where a parameter is represented by a text value, the value in brackets
in the range column is the setting used for serial communications.
Parameter
Range(
Ú)Default(Ö)
Type
Regen Regen
15.01
Supply current magnitude {0.11} ±Maximum drive current A RO Bi P
15.02 Supply voltage {0.12} 400V drive: 0 to 528 V RO Uni P
15.03 Supply power {0.13}
± P
max
kW
RO Bi P
15.04 DC Bus voltage {0.14} 400V drive: 0 to 830 V RO Uni P
15.05 Supply frequency {0.15} ±100 Hz RO Bi P
15.06 Input inductance {0.16} 0.001 to 100 mH RO Uni P
15.07 DC Bus voltage set-point {0.17} 400V drive: 0 to 800 V 400V drive: 700 RW Uni
15.08 Switching frequency {0.18} 3 (0), 4.5 (1), 6 (2), 9 (3), 12 (4) kHz 0 RW Txt P
15.09 High stability space vector modulation {0.19}0 or 1 0RWBit
15.10 Quasi-square operation select {0.20}0 or 1 0RWBit
15.11 Sinusoidal rectifier synchronising {0.21}0 or 1 RO Bit P
15.12 Sinusoidal rectifier synchronised {0.22}0 or 1 RO Bit P
15.13 Sinusoidal rectifier phase loss {0.23}0 or 1 RO Bit P
15.14 Close soft start contactor {0.24}0 or 1 RO Bit P
15.15 Soft start contactor is closed {0.25}0 or 1 RO Bit
15.16 Enable motor drive {0.26}0 or 1 RO Bit P
15.17 Line synchronisation trip enable {0.27}0 or 1 0ROBit
15.18 Line synchronisation status {0.28}
SYNC (0), Ph Det (1), Fr Lo (2), Fr Hi (3),
PLL OI (4), PLL Ph (5)
RO Txt P
15.19 Current control proportional gain 0 to 30,000 110 RW Uni
15.20 Current control integral gain 0 to 30,000 1,000 RW Uni
15.21 Voltage control proportional gain 0 to 30,000 4,000 RW Uni
15.22 Enable extra mains loss detection 0 or 1 0 RW Bit
RO Read Only parameter
Uni Unipolar variable parameter R Reset required for new value to take effect
Bi Bipolar variable parameter S New parameter-value saved at power-down
RW Read / Write parameter
Txt Text variable parameter P Protected; forbidden as destination parameter
Bit Bit parameter FLC Full-load current (max. continuous), Pr
11.32 {0.33}
3I
MAX
×
Pr 5.09
1000
-------------------
×
NOTE
