Table 11-7 RFI Filter terminal data
For all the RFI filters, except the size 5 (4200-6115), the power
connections are screw terminals and the ground connections are stud
terminals
11.1.20 Electromagnetic compatibility (EMC)
This is a summary of the EMC performance of the drive. For full details,
refer to the Unidrive EMC Data Sheet which can be obtained from the
supplier of the drive.
Immunity
Compliance with immunity standards does not depend on installation
details. drives meet EN50082-2 (generic immunity standard for the
industrial environment) and the following specifications from the
IEC61000-4 group (derived from IEC801):
Part 2 Electrostatic discharge: Level 3
Part 3 Radio frequency field: Level 3
Part 4 Transient burst
Level 4 at the control terminals
Level 3 at the power terminals
Part 5 Surge (at the AC supply terminals)
(as specified by EN50082-2 informative annex):
Level 4 line-to-ground
Level 3 line-to-line
Part 6 Conducted radio frequency: Level 3
Emission
Compliance with emission standards depends on rigorous adherence to
the installation guidelines, including the use of the specified RFI filter in
the AC supply circuit. Compliance also depends on the PWM switching
frequency used in the output stage of the drive, and the length of the
motor cable. For full details, refer to the Unidrive EMC Data Sheet which
can be obtained from the supplier of the drive.
When installed according to the instructions the drive can meet the
emission requirements of CENELEC generic emission standards, as
follows:
Table 11-8 Unidrive emission standards
* Compliance with EN50081-1 is restricted to motor cable lengths less
than 100m.
For compliance the optional RFI filter specified below must be used:
Power Drive Systems standard EN61800-3
The drive meets the immunity requirements of EN61800-3 irrespective of
the environment in which it is operating.
The emission requirements of this standard are also met depending on
the environment category, as shown in the table later on this page.
EN61800-3 defines the following:
• The first environment as one that includes domestic premises. It also
includes establishments directly connected without intermediate
transformers to a low-voltage power supply network which supplies
buildings used for domestic purposes.
• The second environment is one that includes all establishments
other than those directly connected to a low-voltage power supply
network which supplies buildings used for domestic purposes.
• Restricted distribution is defined as a mode of sales distribution in
which the manufacturer restricts the supply of equipment to
suppliers, customers or users who separately or jointly have
technical competence in the EMC requirements of the application of
drives.
CT
part
number
Schaffner
part
number
Power
connections
Ground
connections
Max
cable
size
Torque Size Torque
4200-6104 FS5101-10-07
4 mm
2
10 AWG
0.8 N m
7.1 lb in
M5
2.2 N m
19.5 lb in
4200-6105 FS5111-10-29
4 mm
2
10 AWG
0.8 N m
7.1 lb in
M5
2.2 N m
19.5 lb in
4200-6108 FS5106-16-07
4 mm
2
10 AWG
0.8 N m
7.1 lb in
M5
2.2 N m
19.5 lb in
4200-6109 FS5112-16-07
4 mm
2
10 AWG
0.8 N m
7.1 lb in
M5
2.2 N m
19.5 lb in
4200-6113 FS5106-25-07
4 mm
2
10 AWG
0.8 N m
7.1 lb in
M5
2.2 N m
19.5 lb in
4200-6114 FS5113-25-29
4 mm
2
10 AWG
0.8 N m
7.1 lb in
M5
2.2 N m
19.5 lb in
4200-6116 FS5113-50-53
10 mm
2
6 AWG
4.5 N m
3.3 lb ft
M5
2.2 N m
19.5 lb in
4200-6117 FS5113-63-34
10 mm
2
6 AWG
4.5 N m
3.3 lb ft
M6
4.0 N m
2.9 lb ft
4200-6106 FS5113-100-35
50 mm
2
1/0 AWG
8.0 N m
5.9 lb ft
M8
9.0 N m
6.6 lb ft
4200-6107 FS5113-150-40
95 mm
2
4/0 AWG
20.0 N m
14.7 lb ft
M10
18.0 N m
13.3 lb ft
4200-6111 FS5113-180-40
95 mm
2
4/0 AWG
20.0 N m
14.7 lb ft
M12
20.0 N m
14.7 lb ft
4200-6112 FS5113-220-37
150 mm
2
6/0 AWG
30.0 N m
22.1 lb ft
M12
20.0 N m
14.7 lb ft
4200-6115 FS5113-300-99 M12 stud
30.0 N m
22.1 lb ft
M12
stud
20.0 N m
14.7 lb ft
Unidrive EN50081-1
conducted
EN50081-1
radiated
EN50081-2
conducted
EN50081-2
radiated
1 Restricted
motor cable
length*
No Yes Yes
2 Restricted
motor cable
length*
No Yes Yes
3 No No Yes Yes
4 No No Yes Yes
5 No No Yes Yes
Model
RFI filter
Mounting
style
CT part
number
Schaffner part
number
UNI1201 to UNI1205
UNI1401 to UNI1405
Footprint or
Bookcase
4200-6104 FS5101-10-07
Bookcase 4200-6105 FS5111-10-29
UNI2201 to UNI2202
UNI2401
Footprint or
Bookcase
4200-6108 FS5106-16-07
Bookcase 4200-6109 FS5112-16-07
UNI2203
UNI2402 to UNI2403
Footprint or
Bookcase
4200-6113 FS5106-25-07
Bookcase 4200-6114 FS5113-25-29
UNI3201 to UNI3202
UNI3401 to UNI3403
Bookcase 4200-6116 FS5113-50-53
UNI3203
UNI3404
Bookcase 4200-6117 FS5113-63-34
UNI3204
UNI3405
Bookcase 4200-6106 FS5113-100-35
UNI4401 to UNI4402 Bookcase 4200-6107 FS5113-150-40
UNI4403 to UNI4404 Bookcase 4200-6111 FS5113-180-40
UNI4405 Bookcase 4200-6112 FS5113-220-37
UNI5401 Bookcase 4200-6115 FS5113-300-99
