Manual Addendum
1010FMA-4
SETUP PROCEDURE FOR “WET-FLOW CALIBRATED” 1010 SYSTEM
1. INTRODUCTION
When the system 1010 is wet-flow calibrated, the flow computer stores the installation
parameters in its storage memory. Each flow calibration is assigned a unique site name.
Usually, the site name corresponds to the pipe size. For example, a 3-inch carbon steel,
schedule 40 pipe would be given the name “3CS40.”
The flow calibration report issued with each wet-flow calibration, includes a flow cali-
bration “Diagnostic Data Sheet.” This data sheet lists the site name and other neces-
sary information (such as transducer serial number and spacing information), for set-
ting-up the flowmeter. A wet-flow calibration applies to a specific flowmeter and set of
transducers; identified by serial numbers on the diagnostic data sheet.
NOTE: In order for the flow calibration to be valid, the flow computer and trans-
ducers being used must have the same serial numbers as those listed for
the site on the Calibration Diagnostic Data Sheet.
2. SETUP PROCEDURE
2.1 Transducer Installation
2.1 . 1 Refer to the diagnostic data sheet to find the mounting mode (Direct or Reflect)
used during the wet-flow calibration. Review the transducer installation guide-
lines in your 1010 field manual.
2.1 . 2 Refer to the diagnostic data sheet for the transducer spacing index utilized dur-
ing the flow calibration. Using the mounting configuration employed during the
flow calibration, install the transducers on the pipe at the above noted spacing
positions in accordance with the instructions provided on the transducer instal-
lation drawings.
2.1 . 3 Attach the transducer cables noting that the cable marked “UP” attaches to the
transducer closest to the source of flow.
NOTE: Before proceeding further, ensure that the pipe is full of liquid. It is not
important at this point that it be flowing.
1
Caution: DO NOT use the field manual installation procedure to startup a
wet-flow calibrated system. Doing so could void the calibration by
corrupting essential data. This addendum contains the only autho-
rized instructions to be used when commissioning a wet-flow cali-
brated 1010 system.
