4-1
4.0 DRIP PAN ACCESSORY INSTALLATION
The drip pan is offered as an accessory for the Adaptis family of products for customers who
either do not have a drain connection close to the unit, or who simply prefer to avoid using
such a connection. The drip pan accessory can hold up to 4 litres of water although it is
recommended not to exceed the 2 litre capacity.
Check the drip pan regularly (preferably before and after watering plants) and try to keep it
empty and clean.
4.1 Accessory components
The Adaptis A1000 drip pan accessory (P/N 220685) is composed of the following elements:
P/N 220685– Drip pan accessory- A1000
Item Qty Description Picture
A 1 Drip pan
B 1 Drip pan base
C 4 Drawer glides
D 2 Guides (L=762 mm; 30”)
E 8 M3 x 6 countersunk screws
F 4
M3 x 16 sheet metal screws
