2-17
Figure 2.38: Bottom shelf and one light
fixture showed.
Figure 2.38a: of unit
with lamps installed and
program running.
Note: The maximum operating levels
of light for this Kit must be set at the
controller. To edit the factory default
setting, follow the set up instructions
in the CMP 6010 Operator’s Manual
Section 6: Options -- Setup
2.4 Arabidopsis
Kit parts
The following list comprises the components for the AR kit.
Item Qty Description Picture
A 1 Back plenum bottom
B 1 Back wall plenum
C 24 Screw M4 x 6 Pan
D 8 Self support (clip)
