6.
Weld the brackets (screwed to the appliance feet) perma‐
nently onto the top cover along the edges shown.
7.
Tighten all 8 screws on the brackets for the appliance feet,
and remove the covers from the side of the appliance feet.
8.
Use the adjusting screw to level the appliance until it is
seated horizontally. Use the foot-adjustment tool or an ad‐
justable pipe wrench to adjust the adjusting screw, and a
spirit level to check all horizontal surfaces are level.
The absolute tilt of the appliance in operation must not ex‐
ceed max. 2° (3.5%).
Additional information:
The foot-adjustment tool is included with the customer
documentation
5 Setting up the appliance
69
