Convotherm 4 User Manual

5.2.4 How to Semi-Automatically Clean the Cooking Compartment in Floor-Standing
Models
87
5.2.5 How to Clean the Cooking Compartment Without Using Cleaning Agents 90
5.2.6 How to Clean the Double Glass Door 92
5.2.7 How to Clean the Cooking Compartment Section Behind the Suction Panel 93
5.2.8 How to Clean the Hygienic Plug-In Gasket Thoroughly 95
5.3 Specific Cleaning Instructions 96
5.3.1 Safely Using the Appliance 97
5.3.2 Replacing the Rinse Aid Canister 98
5.3.3 Replacing the Cleaning Agent Canister 100
5.3.4 Adding Cleaning Agent from Single-Measure Dispensing Bottles to the Inside of
the Cooking Compartment
101
5.3.5 Emptying the Loading Trolley’s Condensate Drain Pan 103
5.3.6 Releasing the Suction Panel and Locking it Back in Place 105
5.3.7 Removing and Installing the Hygienic Plug-In Gasket 107
5.3.8 Releasing the Inner Glass Door and Locking it Back in Place 109
6 How to Perform Maintenance on the Combi Steamer 112
6.1 Maintenance Basics 113
6.1.1 Warranty Information / How to Contact Customer Service 114
6.1.2 Maintenance schedule 115
6.2 Troubleshooting 116
6.2.1 Troubleshooting – Error Codes 117
6.2.2 Emergency Mode 118
6.2.3 Troubleshooting – Problems During Operation 120
6.3 Maintenance work 122
6.3.1 Working Safely When Performing Maintenance 123
6.3.2 Replacing the hygienic plug-in gasket 124
6.3.3 Replacing the oven light halogen lamp 125
Table of Contents
Operating Manual 6

Convotherm 4 Specifications

General

Model	Convotherm 4
Type	Combination Oven
Temperature Range	30°C to 300°C
Hygienic Door Handle	Yes
Construction	Stainless steel
Cooking Modes	Convection, Steam, Combination
Energy Source	Electric
Cleaning System	Automatic Cleaning System
Power Supply	400V
