Service manual OEB/OES/OGB/OGS
AS/11-2011 3_06e_Basic settings service level_et_c.doc
Page 5 / 7
3.6.3 How to work with the diagnosis system in the service programme
Instructions:
You are already in the basic settings service level
To get to the service programme
press the "Service" symbol on
the screen
Enter the password "1qaz" with
the aid of the input keyboard and
confirm your selection by
pressing "" (Caution: In the
dummy mode the password is
"A").
You will enter the service programme that is divided into up to 6 subcategories
(tabs). Press the tab to call up the desired subcategory.
1. Settings = target values
2. Visual = flow chart of the appliance functions
3. I/O = inputs and outputs
4. Individual = appliance start from the service programme (for gas settings)
5. IDM
6. Gas = gas setting parameter (only shown for gas appliances and in dummy
mode ).
