Optional equipment and accessories
Installation manual 78
Connecting the CONVOClean system
Follow the steps below to connect the CONVOClean system:
Step Action
1
Mix the supplied CONVOCare concentrate with soft water in the empty CONVOCare canister.
Follow the instructions in the user manual on mixing the CONVOCare solution.
2 Plug the red extractor tube (4) for the cleaning agent onto the connector nipple of the front tube fitting
(G) and hold in place with the wire clip (3).
3 Plug the transparent extractor tube (2) for the detergent onto the connector nipple of the front tube
fitting (F) and hold in place with the wire clip (3).
4 Plug the red suction nozzle into the canister of CONVOClean forte (5). There must be no kinks in the
tube and the vent hole in the canister must be open and unblocked.
5 Plug the transparent suction nozzle into the canister of CONVOCare (1). There must be no kinks in
the tube and the vent hole in the canister must be open and unblocked.
6 Inform the user that the appliance must not be opened during cleaning. There is a risk of chemical
burns to the eyes.
Optional customization
As an option, the CONVOClean system can be customized to suit the user's requirements by a trai-
ned service engineer with access to the Service level (service manual).
