3.1.1.Measurements with EM 6400 DigitAN series
The EM 6400 DigitAN can measure, locally display and remotely transfer over MODBUS RTU, the
following electrical parameters over the input range with an accuracy of Class 1.0 or better for Volts
and Amps, Power and Energy functions, Class 0.5 is optional:
Table 2.4a: Measurements with EM 6400 DigitAN series meters
Parameters
EM
6459
EM
6433
EM
6434
EM
6436
EM
6400
True RMS voltage phase to neutral and
3phase average
•
• •
True RMS voltage phase to phase and
3phase average
•
• •
True RMS current per phase and 3phase
average
• •
• •
Frequency
•
• •
Power Factor
•
• • •
Real Power and Energy
• • • •
Reactive Power and Energy
•
•
Apparent Power and Energy
•
•
OLD Real Power and Energy
• • • •
OLD Reactive Power and Energy
•
•
OLD Apparent Power and Energy
•
•
Import/Export Parameters (Ordering
Option) - VAh, Wh, VARh (Ind and
Cap), Run hours, On hours,
Interruptions
•
Demand Parameters (Ordering
Option)
(W/VA Demand, Rising Demand,
Maximum Demand, Maximum Demand
Time, Time remaining)
•
Total Harmonic Distortion (Ordering
Option)
(V1%, V2%, V3%, A1%, A2%, A3%)
•
Note: This document is applicable for:
All models - v03.02.12.
EM6400, EM6459, EM 6434 – v03.02.02.
EM 6436, EM 6433 – v03.02.11.
The EM 6400 provides all single phase (per-phase) Real, Apparent, Reactive Power and
Power Factor values. Positive (Inductive) and Negative (Capacitive) Reactive Energy is
separately accumulated for Lead / Lag analysis. OLD Energy values for VAh, Wh, VARh, -
VARh is available.
