& Power Supply Idle Control
(Note 1)
Enables or disables Package C6 State.
Typical Current Idle Disables this unction.
Low Current Idle Enables this unction.
Auto Lets the BIOS automatically congure this setting. (Deault)
& CCD Control
(Note 1)
Sets the number o CCDs to be used. (Deault: Auto)
& Downcore Control
Allows you to select the number o CPU cores to enable (the number o CPU cores may vary by CPU).
(Deault: Auto)
& SMT Mode
Allows you to enable or disable the CPU Simultaneous Multi-Threading technology. (Deault: Auto)
& CPPC
(Note 1)
Enables or disables the CPPC eature. (Deault: Auto)
& CPPC Preferred Cores
(Note 1)
Enables or disables the CPPC Preerred Cores eature. (Deault: Auto)
& Extreme Memory Profle (X.M.P.)
(Note 2)
Allows the BIOS to read the SPD data on XMP memory module(s) to enhance memory perormance when
enabled.
Disabled Disables this unction. (Deault)
Prole1 Uses Prole 1 settings.
Prole2
(Note 2)
Uses Prole 2 settings.
& XMP High Frequency Support
(Note 2)
Allows you to select the compatibility level or high-requency memory. This item is congurable only when
Extreme Memory Profle (X.M.P.) is set to Profle1 or Profle2. (Deault: Auto)
& System Memory Multiplier
Allows you to set the system memory multiplier. Auto sets memory multiplier according to memory SPD
data. (Deault: Auto)
 Advanced Memory Settings
 Memory Subtimings
d Standard Timing Control, Advanced Timing Control, CAD Bus Setup Timing, CAD Bus
Drive Strength, Data Bus Confguration
These sections provide memory timing settings. Note: Your system may become unstable or ail to boot
ater you make changes on the memory timings. I this occurs, please reset the board to deault values by
loading optimized deaults or clearing the CMOS values.
 SPD Info
Displays inormation on the installed memory.
& CPU Vcore/Dynamic Vcore(DVID)/VCORE SOC/Dynamic VCORE SOC(DVID)/CPU VDD18/
CPU VDDP/A_VDD18S5/DRAM Voltage (CH A/B)/DDRVPP Voltage (CH A/B)/DRAM
Termination (CH A/B)
These items allow you to adjust the CPU Vcore and memory voltages.
 CPU/VRM Settings
This submenu allows you to congure Load-Line Calibration level.
(Note 1) This item is present only when you install a CPU that supports this eature.
(Note 2) This item is present only when you install a CPU and a memory module that support this eature.
