1-7 Internal Connectors
Read the ollowing guidelines beore connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Beore installing the devices, be sure to turn o the devices and your computer. Unplug the power
cord rom the power outlet to prevent damage to the devices.
• Ater installing the device and beore turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX_12V
2) ATX
3) CPU_FAN
4) SYS_FAN1/2
5) D_LED
6) LED_C
7) SATA3 0/1/2/3
8) M2A_CPU
9) F_PANEL
10) F_AUDIO
11) SPEAKER
12) F_U32
13) F_ USB
14) COM
15) TPM
16) CLR_CMOS
17) BAT
4
2
11
1
15
16
3 9
7
12
6
13
4 8 5
10
17
14
- 12 -
