Coolmay CX3G - 5.1.2 Analog Input Reading 1 (v26210;26220)

CX3G/FX3GC PLC Programming manual
www.coolmayplc.com
23
ones, it is up to customers’s need when ordering.
5.1.2 Analog input reading 1 (for software version 26210 and 26220)
Support FROM instruction or register directly read. Such as: FROM K0 K0 D400
K16, read out 16 analog input, 0-10V.
The K-type thermocouple registers read values are shown in the following table:
NO
Register Value
AD0
R23680
AD1
R23681
AD2
R23682
AD3
R23683
Environment temperature
R23684
AD4
R23685
AD5
R23686
AD6
R23687
AD7
R23688
AD8
R23689
AD9
R23690
AD10
R23691
AD11
R23692
AD12
R23693
AD13
R23694
AD14
R23695
A decimal points should be retained for temperature. Namely 182=18.2℃.
Other types of read values are as the following table:
NO
PT100 register
read value
NTC10K register
read value
0~10V/0-5V or
0~20mA
4~20mA register
read value
