CX3G/FX3GC PLC Programming manual
www.coolmayplc.com
R23960 starts with a zero correction value and defaults to 0.
5.1.5 Analog input sampling
Filtering cycles=( R23600~R23615)* PLC scanning time, if R23600=1, sample
one time each scan circle and change the 1
st
analog value for one time. The larger
R23600~R23615 value is, the result is more stable.
R23600~R23615 is filtering cycles, default is 0;
D8073 is smoothing filter coefficients of all analog input, range: 0~999
5.2 Analog output
Analog output range 0~4000, precision is 12 bit. Support TO instruction or register
assignment operation directly.
Adopts TO K0 K0 D500 K8, 8 channels 0~10V or 0~20mA analog output.
Register assignment operation directly: D8050~D8057.
When the analog output is current, the bit of D8058 needs to be set:
When the default D8058.0~D8058.7=0, it means 0~20mA; when
D8058.0~D8058.7=1, it means 4~20mA.
