Coolmay CX3G - 5.1.3 Analog Input Reading 2 (v26220)

CX3G/FX3GC PLC Programming manual
www.coolmayplc.com
24
register read value
AD0
R23640
R23660
D8030
R23620
AD1
R23641
R23661
D8031
R23621
AD2
R23642
R23662
D8032
R23622
AD3
R23643
R23663
D8033
R23623
AD4
R23644
R23664
D8034
R23624
AD5
R23645
R23665
D8035
R23625
AD6
R23646
R23666
D8036
R23626
AD7
R23647
R23667
D8037
R23627
AD8
R23648
R23668
D8038
R23628
AD9
R23649
R23669
D8039
R23629
AD1
0
R23650
R23670
D8040
R23630
AD1
1
R23651
R23671
D8041
R23631
AD1
2
R23652
R23672
D8042
R23632
AD1
3
R23653
R23673
D8043
R23633
AD1
4
R23654
R23674
D8044
R23634
AD1
5
R23655
R23675
D8045
R23635
When it is less than 3.8mA, the value is 32760, that is off line.
5.1.3 Analog input reading 2 (for software version 26220)
Thermocouple K-type (minus temperature), T-type, T-type (minus temperature)
