5.3 PID instruction
Detailed information please refer to <Mitsubishi FX3G Programming Manual>
The self-tuning method in the PID instruction has only a step response mode.
The step value is S0+22.
DA register
Range
Output type
DA0
D8050
0-4000
When D8058.0~D8058.7=0
Means 0~20mA；
When D8058.0~D8058.7=1
Means 4~20mA。
DA1
D8051
0-4000
DA2
D8052
0-4000
DA3
D8053
0-4000
DA4
D8054
0-4000
DA5
D8055
0-4000
DA6
D8056
0-4000
DA7
D8057
0-4000
