Center interpolation
1
0
Radius interpolation
1
1
The direction and coordinates of the center and radius interpolation are as shown in
the following table: (26234 version has no interpolation function)
26233 version and above
Clockwise
M8348 = 0
Anticlockwise
M8348 = 1
Relative coordinate
M8344 = 0
Absolute coordinate
M8344 = 1
D8340 shows the current address of X axis,D8350 shows the current address of Y
axis
。
In CoolMay 3G PLC,interpolation motion still adopts DPLSR for pulse output.
Description of the Operand:
S. represents the pulse frequency, that is, the speed of the interpolation motion.
S.+2 represents the X-axis target address.
S.+4 represents the Y-axis target address.
D.: Specify the Y number with pulse output (currently only Y0 is supported), and
the default Y1 is another axis.
26235 version and above
Clockwise
M8435 = 0
Anticlockwise
M8435 = 1
Relative coordinate
M8434 = 0
Absolute coordinate
M8434 = 1
