37
Option 2-9-2:
Printing the Log
If a printer is connected to the control unit,
you can print some or all of the events
recorded in the log.
User 2 Menu 9
Log
1. Press [ to select this option.
Log Functions 2
Print Log
2. Use | or ¬, or press 2 to select Print
Log, then press [.
How many events?
0030
3. Choose the number of events to print
by using | or ¬, or by entering the four-
digit value, then press [.
With offset of:-
0030
4. Specify an offset by using | or ¬, or by
entering the four-digit value, then press
[. If, for example, you choose to print
10 events and an offset of 50, the
system will print events 50-59 (with event
number 1 being the most recent).
Z
There may be more than one printed
line per log event.
If you want to stop the current print job, re-
print the log, and specify zero events to
print.
Once you have used the Print Log option,
the system goes into online printing mode,
where every action is immediately printed.
Switch off the printer to stop all printing.
To Next Page
