Before Placing the Recloser Control
into Service
Prior to placing the Form 6 recloser control into service,
installation procedures must be properly completed and
verified.
For information on placing the control into service refer to
the appropriate instructions:
• Service Information S280-70-1 Form 6 Rack Mount
Control Installation and Operation Instructions
• Service Information S280-70-2 Form 6 Yard Mount
Control Installation and Operation Instructions
• Service Information S280-70-3 Form 6 Pole Mount
Control installation and Operation Instructions
• Service Information S280-70-7 Form 6 Triple-Single
Pole Mount Control Installation and Operation
Instructions
INSTALLATION
Initial Programming Prior to
Installation
The control must be programmed with all necessary
operating settings, all alternate profiles, and parameters
prior to operation with an energized recloser.
Note: Initial programming of the control is the responsibility of
a qualified technician or engineer familiar with control
functions and programming parameters required for the
specific recloser installation.
The control must be programmed with the Form 6
ProView interface software. Refer to the appropriate con-
trol programming guide for information:
• S280-70-4 Form 6 Control Programming Guide
• S280-70-9 Form 6 Triple-Single Pole Mount Control
Programming Guide
S280-70-11
9
CAUTION: Equipment misoperation. Do not
connect this control to an energized recloser until
all control settings have been properly programmed
and verified. Refer to the programming information for
this control. Failure to comply can result in control and
recloser misoperation, equipment damage, and per-
sonal injury. G110.3
CAUTION: Equipment misoperation. Do not
connect this control to an energized recloser until
all control settings have been properly programmed
and verified. Refer to the programming information for
this control. Failure to comply can result in control and
recloser misoperation, equipment damage, and per-
sonal injury.
G110.3
IMPORTANT: Program all protection profiles.
Unused alternate profiles should be programmed with
the same settings as one of the applicable profiles.
Default settings on unused alternate profiles can cause
unnecessary outages if they are below normal system
requirements.
CAUTION: Equipment misoperation. Check mini-
mum trip values prior to changing an alternate profile.
Failure to do so may cause misoperation of the control
under load conditions. T280.0
