Cooper VW - Page 21

S280-30-7
21
Item Catalog Quan.
No. Description Number Req’d.
42 Groove pin KP3124A50 3
43 Insulation barrier KRW125N1 3
44 Wire tie, Panduit#SST4H K994904170004A 12
45 Upper stringer assembly KA62R 9
46 Insulating tubing KP3230A14 9
47 Lead mounting bracket KP1061VWS 3
48 Machine screw, rd hd,
1/4-20 x 1 brass K721525125100A 3
49 Fuse mounting clip KP2006A16 2
50 Lead assembly KA28W1 2
51 Flat washer, #14S, brass K900525026056A 3
52 Split lockwasher, med, 1/4, brz K900830025000A 7
53 Hex nut,1/4-20, brass K881025120025A 7
54 Spring KP1066VWS 6
55 Upper current exchange assy.
Phases A and B KRW115FB 2
Phase C KRW115FA 1
56 Machine screw, rd hd,1/4-20
X 3/8, brass K721525125037A 4
57 Closing coil fuse assembly
(also included in closing coil
replacement kit, Figure 28,
item 36).
2.4-3.3 kv (2 red color bands) KA259R904 2
4.16-6 kv (black color band) KA259R901 2
7.2 to 11 kv (yellow color band) KA259R902 2
12 to 24.9 kv (red color band) KA259R903 2
58 Closing solenoid contactor
Type VW KA430R1 1
Type VWV27 and VWV38 KA430R3 1
59 Contactor toggle spring KP141R 2
60 Groove pin KP1306R 1
61 Retaining ring, Type C,1/4” stl K970901250000M 4
62 Capscrew, hex hd,1/4-20 x 1/2
with preassembled split
lockwasher, stl K830101125050A 3
63 Lower stringer assembly KA222VS 9
64 Lower current exchange and
support plate assembly
Phases A and B KRW446VB 2
Phase C KRW446VA 1
65 Flat washer, SAE, 3/8, stl K900201037000A 9
66 Split lockwasher, med, 3/8, stl K900801037000Z 9
67 Hex nut, 3/8-16, stl K880201116037A 9
68 Spacer KP3009A11 3
69 Interrupter clamp KP1036VS 12
70 Capscrew, hex socket hd
1/4-20 x 1, stl KP2036A10 12
71 Vacuum interrupter
Type VW S/N 3104 and before
Phase A & B KRW705VA 2
Phase C KRW705VB 1
Type VWV S/N 976 and before
Phase A & B KRW705VC 2
Phase C KRW705VD 1
Type VW S/N 3105 and after KA215VS2 3
Type VWV 27 S/N 977 and
after KA227VS2 3
Type VWV38 KA238VSA2
72 Long bushing lead
(6 per phase) KP3250A27 18
73 Long lead insulation KP2106A77 3
74 Toggle assembly KA450R1 1
Trip Coil and Interrrupter Mechanisms(Figure 27)
Item Catalog Quan.
No. Description Number Req’d.
1 Time-delay unit replacement
kit complete (includes
attaching screws)
For B and C curves KA1194R1 3
For D and E curves KA1194R2 3
2 Trip link assembly, complete KA161R 3
3 Torsion spring KP576R 3
4 Roll pin, 1/8 X 3/4, stl K970801125075M 3
5 Trip lever stop KP577R 3
6 Retaining ring, Type C,
1/4, stl K970901250000M 3
7 Groove pin KP3114A1 3
8 Spacer KP3007A12 3
9 Cotter pin, 1/16 X 1/2. stl K970501062050A 3
10 Capscrew, hex hd,
3/8-16 x 1-3/4, brass K730125137175A 3
11 Flat washer, #24S, brass K900525039087H 12
12 Spacer KP3013A63 3
13 Split lockwasher med 3/8,
sil brz K900830037000A 9
14 Hex nut, 3/8-16, brass K880225116037H 9
15 Capscrew, hex hd, 3/8-16 X 1”,
sil brz K730133137100A 6
16 Short lead (6 per phase) KP3250A1 18
17 Short lead insulation KP2106A80 3
18 Coil strap (400X and 560X trip
coils only) KP1085VWS 3
19 Capscrew, hex hd,1/2-13 x 1,
sil brz K730133150100A 3
20 Split lockwasher, med,
1/2, sil brz K900830050000A 3
21 Hex nut,1/2-13 sil brz K880133113050A 3
22 Trip solenoid assembly
(includes items 25 thru 36)
Phases A and B KA134VWS2 2
Phase C KA134VWS1 1
23 Flat washer, SAE,1/4, stl K900201025000Z 6
24 Elastic stop nut,1/4 KP2020A3 6
25 Self-tapping screw, rd hd
Type F. #2 x 5/16. stl K751501102031 A 6
26 Eyelet KP1351 R 6
27 Guide KP622R 6
28 Solenoid plunger assembly KA604R 3
29 Plunger guide KP312R 6
30 Capscrew, hex hd,
1/4-20 x 7/8 stl K730101125087A 6
31 Solenoid frame KA603R 3
32 Series coil replacement kit
(includes item 20, Figure 26)
(Add coil rating as suffix
to catalog number)
Phases A and B KA835W2- 2
Phase C KA835W1- 1
33 Isoglass sleeve (not used with
with 400X and 560X coils) KP2104A15 3
34 Coil washer KP318R 6
35 Coil washer (used with 400,
400X, 560 and 560X coils) KP1075R 3
36 Barrier KP1684R1 3
37 Contact rod assembly KA111VWS 3
38 Spacer KP3007A49 3
39 Groove pin KP3124A76 3
40 Retaining ring, Type C,
1/4”, stl K970901250000M 12
41 Capscrew, hex hd, 1/4 X 1/2
with captive lockwasher, stl K830101125050A 6
