Item Catalog Quan.
No. Description Number Req’d.
33 Hex nut, 3/8-16, stl K880201116037A 4
34 Solenoid frame KP100R2 1
35 Capscrew, 3/8-16 x 1-1/2, stl K730101137125A 8
36 Closing coil replacement kit
(includes closing coil, lower coil
gasket 37 (Figure 28), two fuse
assemblies 57 (Figure 27), and
voltage data plate, 19
Figure 26).
Type VW and VWV27 reclosers
below 20 kv
2.4 kv KA834R1
3.3 kv KA834R10
4.16-4.8 kv KA834R2
6.0 kv KA834R6
7.2-8.32 kv KA834R3
11.0 kv KA834R9
12.2-13.2 kv KA834R4
14.4 kv KA834R5
17.0 kv KA834R12
20.0 kv KA834R11
Type VWV27 and VWV38
reclosers 20 kv and above
23.0-24.9 kv KA834R13
34.5 kv KA834R14
Reclosers with low voltage
closing
48 vdc KA834R16*
125 vdc KA834R7*
250 vdc KA834R8*
37 Solenoid gasket KP389R 1
38 Solenoid frame post KP1669R 4
39 Solenoid bridge plate
assembly KA644R3 1
Closing Solenoid and Hydraulic Contol Parts(Figure 28)
Item Catalog Quan.
No. Description Number Req’d.
1 Capscrew, hex socket hd,
1/2-13 x 4-1/2, stl KP2036A3 6
2 Split lockwasher, med, 1/2,
stl K900801050000Z 6
3 Spacer KP3182A1 6
4 Counter shaft coupler KP2448R 1
5 Operating lever coupler KP2447R 1
6 Pivot pin KP418H 1
7 Retaining ring, Type C, 1/4,
stl K970901250000M 1
8 Lockout piston link KP122R 1
9 Pin KP3055A3 1
10 Lockout piston KP112R 1
11 Spring clip KP2018A1 1
12 Pump link KA97R 1
13 Pump piston KP1733R 1
14 Pin KP3055A1 1
15 Pump piston shell KP1732R 1
16 Retaining ring, Type E, 1/8”,
stl K971001125000A 1
17 Quick reset valve assembly KA423R 1
18 Pump and lockout piston
block KP1300R 1
19 Capscrew, hex hd,
1/4-20 x 1-3/4, stl K730101125175A 2
20 Split lockwasher, med, 1/4,
stl K970801025000A 2
21 O-ring gasket KP2000A3 2
22 Ball KP2025A2 2
23 Ball seat KP155H2 2
24 Ball retainer pin KP3051 A3 1
25 Ball retainer pin KP3051A1 1
26 Gasket KP116R 1
27 Retaining ring, Type C,
3/8”, stl K970901312000M 2
28 Groove pin KP3126A2 1
29 Flat washer, SAE, 3/8, stl K900201037000A 2
30 Plunger and link assembly KA50R 1
31 Stringer assembly KA62R 4
32 Split lockwasher, med,
3/8, stl K900801037000Z 12
*
No fuses required with low-voltage dc coils when converting a
recloser for low-voltage operation use low-voltage contactor and coil
kit KA887R; specify desired operating voltage (Vdc or Vac).
