English
Operating instructions
17
- Stop the beater by pressing the relative button [K2], put a basin under the Extraction door and open the door eliminating
the solution from the cylinder;
- Close the Extraction door and rinse repeating the operation with fresh water.
7.2 Disassembling of the parts
To facilitate the maintenance all parts which come in contact with the product can be disassembled directly by the user, in
a fast and simple way, without using any tool.
CARRY OUT THESE OPERATIONS ONLY WITH THE SOCKET'S MAIN BREAKER ON “0”. THE [Z1] INDI-
CATOR OF THE IGNITION BUTTON MUST BE TURNED OFF.
- Carry out rinsing operations (ref. Par. 7.1) in order to easily reach machine's parts;
- extract the rod [25] from the lid’s hinge and remove the lid [5];
- Unscrew counterclockwise the fixing knob [7] and extract the beater [6];
RESIDUAL HAZARD: BEATER'S BLADE ARE SHARP ALONG BOT-
TOM AND EXTERNAL SIDE EDGES. IT IS RECOMMENDED TO USE SUIT-
ABLE PROTECTIVE GLOVES AND TO HANDLE THE BEATER ONLY BY
HOLDING THE CENTRAL HUB AND NOT THE BLADES.
- remove the basin support [10] by unscrewing the hand screws [16];
- unscrew the hand screw [16] to remove the chute [9];
- for a thorough wash, separate blades [36] (take care not to loose screws).
7.3 Accurate washing
THESE OPERATIONS MUST BE CARRIED OUT ONLY WITH THE BEATER
AND THE LID REMOVED FROM THE DEVICE AND WITH THE SOCHET'S
MAIN BREAKER ON “0”.
TAKE CARE NOT TO ALLOW WATER OR ANY LIQUID INSIDE THE MA-
CHINE.
Two or 3 times per week and in any case as provided by in force laws, we suggest to wash and clean with extreme care all
parts of the device in direct contact with the product, during which all components which can be disassembled must be
removed from the device (ref. Par. 7.2) and separately washed. Use cool water and a detergent integrated for foods; then
rinse with cool water.
Note: For a long life of the device we suggest not to use too hot water, solvents, abrasive detergents, or rough
sponges, in particular on the plastic parts.
