Corema GAMMA 250 - Reassembly

English
Ice cream freezer
18
Before reassembling the components, accurately wash the fixed parts of the device:
- the extraction pipe and the safety grill, utilising the featured brush;
- the upper deck and the inside of the cylinder;
- the front panel, with particular attention for the extraction door, the relative frame and the basin support zone.
7.4 Reassembly
THESE OPERATIONS MUST BE CARRIED OUT ONLY AFTER DISCONNECTING MACHINE FROM
MAIN POWER!
- Assemble blades [31] on beater's supports [6] partially screwing screws [36]. Blades
will be subsequently adjusted.
Carefully place beater into the cylinder, taking care to keep it
vertical without dropping it.
- The slot on the beater's hub [27] goes into the shaft clutch [28];
- FIRMLY tighten beater's fixing knob [7];
Before tightening knob [7], always check that the gasket [G] is
in perfect conditions and in place, an that is clear of any fat as
to prevent knob from accidentally coming loose. Should the
knob fall into the cylinder during production cycle, it would
cause serious damage to the machine.
Note: Gaskets must be periodically replaced (ref. Par. 8.1).
- put lid in place, insert pin [25];
- install the chute [9] beneath the extraction door [14], by screwing the knob [16];
- fix basin support [10] on the front panel with knobs [16];
